EMERGENCY RESPONSE GUIDE
4
HIGH VOLTAGE BATTERY
Model S is equipped with a floor-mounted 400 volt lithium-ion high voltage battery. Never breach the high voltage battery when lifting from under the
vehicle. When using rescue tools, also pay special attention to ensure that you do not breach the floor pan.
HIGH VOLTAGE COMPONENTS
High voltage battery is located below the floor
WARNING: Regardless of the disabling procedure you use, ALWAYS ASSUME THAT ALL HIGH VOLTAGE COMPONENTS ARE ENERGIZED! Cutting, crushing or touching high voltage
components can result in serious injury or death.
