TN-18-16-001 R2 Page 3 of 15
WARNING:
• Inspect or repair a vehicle that has an unstable battery outdoors or within easy access to the outdoors.
• If an HV battery has been determined to have a coolant leak, do not pressurize the cooling system.
• Store damaged HV batteries at least 15 m (50 ft) away from flammable materials, structures, other vehicles, and
other HV batteries.
• Do not store standalone HV batteries below -20°C (-4°F).
• Do not store standalone HV batteries for over 10 days above 35°C (95°F).
• Do not charge or discharge a standalone HV battery below 0°C (32°F).
• Do not store standalone HV batteries for over 30 days at full state of charge (SOC) or completely discharged.
• Do not charge a damaged or potentially unstable HV battery.
• Do not weld near HV batteries.
HV Battery Assembly Underside
The underside of the HV battery assembly has several key components, as shown in Figure 3.
Figure 3 – HV battery assembly components
