SPECIFICATION
Working voltage 100-240V~50/60 Hz
Dimensions (W x H x D) without stand
32”: 718.2 x 425.9 x 84 mm
40”: 892.3 x 512.8 x 86.7 mm
43”: 954.5 X 558.5 X 86.9 mm
Net weight without stand
32”: 3.5 kg
40“: 5.1 kg
43”: 5.9 kg
RF aerial input 75 ohm unbalanced
Language of OSD Multiple options
System
DTV: DVB-T/T2/S/S2/C
ATV: PAL/SECAM BG/DK/I
Channel coverage
DVB-S/S2: 950MHz ~ 2150MHz
DVB-T/T2: 50MHz ~ 862MHz
DVB-C: 48MHz ~ 859MHz
ATV: 47.25MHz ~ 865.25MHz
Environment
Working temperature: 5ºC~40ºC
Working humidity: 20%~80%
Storage temperature: -15ºC~45ºC
Storage humidity: 10%~90%, non-condensing
Radio Module Specifications
Wireless Network (WLAN)
Frequency Band Transmitting Power (Max.)
2.4G: 2400 ~ 2483.5 MHZ
5G: 5150~5850 MHz
<23dBm
Bluetooth
Frequency Band Transmitting Power (Max.)
2400 ~ 2483.5 MHz <14dBm
Remark:
1. The device should be positioned or operated at least 20cm away from the user.
2. Due to various sales regions, the wireless module may have different configurations which
will not exceed the maximum described in this manual.
3. Restrictions or Requirements in following countries: Indoor use only within 5150-5350MHz.
FR DE UK IT NL BE LU TR
DK IE GR ES PT AT FI LI
SE CY MT PL HU CZ SK IS
SI EE LV LT BG RO HR NO
