Align the connector to the charge port and
insert fully. When the connector is properly
inserted, charging begins automatically after
Model X:
•
Engages a latch that holds the connector
in place;
• Shifts into Park (if it was in any other
drive mode);
• Heats or cools the Battery, if needed. If
the Battery requires heating or cooling,
you may notice a delay before charging
begins.
NOTE: Whenever Model X is plugged in but
not actively charging, it draws energy from
the wall outlet instead of using energy stored
in the Battery. For example, if you are sitting
in
Model X and using the touchscreen while
parked and plugged in,
Model X draws energy
from the wall outlet instead of the Battery.
CAUTION: The connector end of the
charge cable can damage the paint if
you drop it onto Model X.
Charge Port Light
•
WHITE (OR LIGHT BLUE): The charge
port door is open. Model X is ready to
charge and the connector is not inserted,
or the charge port latch is unlocked and
the connector is ready to be removed.
• BLUE:
Model X detects that a connector
has been plugged in.
• BLINKING BLUE: Model X is
communicating with the connector. Either
Model X is preparing to charge, or a
charging session is scheduled to begin at
a specified future time.
•
BLINKING GREEN: Charging is in
progress. As Model X approaches a full
charge, the frequency of the blinking
slows.
• SOLID GREEN: Charging is complete.
• SOLID AMBER: The connector is not fully
plugged in. Realign the connector to the
charge port and insert fully.
•
BLINKING AMBER: Model X is charging at
a reduced current (AC charging only).
•
RED: A fault is detected and charging has
stopped. Check the instrument panel or
touchscreen for an alert.
Charging Status
Charging status displays on the instrument panel when the charge port door is open.
Charging Instructions
205Using the Touchscreen
