Connect the inlet hose
Connecting to a threaded water tap
Connecting to a non-threaded water tap
1. Connect the water hose to
the water tap, and then turn
the connector clockwise as
shown.
1. Remove the adaptor (A)
from the water hose (B).
4. Insert the adaptor onto the water tap.and then
lighten the screws while lifting the adaptor.
5. Turn part(C) in the arrow direction to lighten it.
6. While pulling down parl (D) on the water hose,
connect the water hose to the adaptor. Then,
release parl (D). The hose fits into the adaptor
with a clicking sound.
7. To complete connecting the water hose, see 2
and 3 on the ”Connecting to a threaded water
tap” section.
2. Connect the other end of
the water hose to the inlet
valve on the back of the
washing machine. Turn the
hose clockwise to tighten.
2. Use a Phillips screwdriver
to loosen four screws on
the adaptor.
3. Open the water tap and check
if there are any leaks around
the connection areas. If there
are water leaks, repeat the
steps above.
3. Hold the adaptor and turn
part (C) in the arrow direction
to loosen it by 5mm (*).
