Tesmec AFS303 - Page 42

PULLER
-
TENSIONER
Model: AFS303
TABLE 3.1
1) Crown-pinion lubricator.
2) Anchoring ears.
3) Anchoring ears.
4) Hydraulic oil filter.
5) Hydraulic oil filter.
6) Oil filling cap for diesel engine.
7) Liquid filling cap for diesel engine radiator.
8) Lever for reduction gear speed change.
• pos. C: high pull (normal braking)
• pos. A: idle bull-wheels
• pos. B: low pull (fine braking).
9) Negative brake oil filling cap (IP HYDRUS OIL 46, qty 0.3 liters).
10) Negative brake oil draining plug.
11) Negative brake oil level.
12) Reduction gear oil filling cap (IP MELLANA-220, qty 1.6 liters).
13) Reduction gear oil draining plug.
14) Reduction gear oil level.
15) Control panel.
