4. Technical data12
4. Technical data
Feature Values
Penetration probe
Sensor type NTC
Measuring range 50 to +250 °C / 58 to +482 °F
Resolution 0.1 °C/°F/°R
Accuracy (±1 digit) ±1.0 °C / ±1.8 °F (
-50,0 to-30,1°C / 58.0 to 22.1 °F)
±0.5 °C / ±0.9 °F (
-30,0 to +99,9°C / 22.0 to +211.9 °F)
±1 % of the measuring range (+100.0 to +250.0 °C / +212.0
to +482.0 °F)
Response time t99 10 s (measured in moving liquid)
Measuring rate 0.5 s
Infrared measurement
Lens 10:1 + opening diameter of the sensor (12 mm / 0.47”)
Spectral range 8 to 14 μm
Laser type 2point laser
Output / wavelength < 1 mW / 650nm
Class / standard 2 / DIN EN 608251:2007
Measuring range 30 +250 °C / 22 +482 °F
Resolution 0.1 °C/°F/°R
Accuracy (±1 digit) ±2.5 °C / ±4.5 °F (30.0 to 20.1 °C / 22.0 to 4.2 °F)
±2.0 °C / ±3.6 °F (20.0 to 0.1 °C / 4.1 to 31.9 °F)
±1.5 °C / ±2.7 °F or ±1.5 % of the measuring value (0.0 to
+250.0 °C / +32.0 to +482.0 °F)
Measuring rate 0.5 s
General
Operating temperature 20 to +50 °C / 4 to +122 °F
Transportation/ 30 to +50 °C / 22 to +122 °F
storage temperature
Power supply 2 x AAA batteries
Battery life 10 h (typical at 25°C / 77°F)
Housing ABS/TPE/PC and diecast zinc/stainless steel
Protection class IP65
Dimensions 281 x 48 x 21 mm / 11.06 x 1.89 x 0.83“
(immersion/penetration probe folded out)
178 x 48 x 21 mm / 7.01 x 1.89 x 0.83”
(immersion/penetration probe folded up)
Weight 197g / 0.433lbs (incl. batteries)
Standards EN 13485
EC Directive 2004/108/EC
Warranty 2 years, warranty terms: see www.testo.com/warranty
Information on standards
This product c
with the E
standard for
penetration measurement.
Suitability: S, T (storage, transportation)
Environment: E (transportable thermometer)
Accuracy class: 0.5
Measuring range: -50...+250 °C
According to EN 13485, the measuring instrument should
be checked and calibrated regularly under the terms of
EN 13486 (recommended frequency: yearly).
Contact us for more information.
