Using the product16
material) is displayed with the relevant material number (see
enclosed sticker for the inside of the protective cap).
Settable materials Measuring range
1. beech, spruce, larch, birch, cherry, walnut 8.8...54.8 % by weight
2. oak, pine, maple, ash-tree, douglas fir, meranti 7.0...47.9 % by weight
3. cement screed, concrete 0.9...22.1 % by weight
4. anhydrite screed 0.0...11.0 % by weight
5. cement mortar 0.7...8.6 % by weight
6. lime mortar, plaster 0.6...9.9 % by weight
7. bricks 0.1...16.5 % by weight
> Press several times until the desired material
characteristic curve appears.
Testing the instrument function:
1 Press
several times until Test: lights up.
2 Connect sensing electrodes with the contacts of the test
resistor on the top of the protection cap.
- Test flashes.
-
Test: ok lights up: instrument is functioning.
Test: ok does not light up: test not possible, see chapter
‚Tips and assistance‘.
3 Press
back to measurement menu.
Changing the display view:
Adjustable views
· Current reading
· Hold: Readings are held.
Max/Min-display for air humidity and temperature only.
· Max: Maximum values since the instrument was last switched on or last reset.
· Min: Minimum values since the instrument was last switched on or last reset.
> Press several times until the desired view appears.
Resetting Max/Min values:
1 Press
several times until the desired view appears.
2 Press
and hold until - - - - appears.
3 Repeat steps 1 and 2 for all values that are to be reset.
Switching the instrument off:
> Press
and hold until the display goes out.
