TESY bilight series - Page 79

1ⓕ
1
120 mm
B
D
G
2xG
max 282 mm
min 240 mm
H
L
F
E
A
GCHFS
GCHFS
.
.
.
.
.
.
min 700 mm
B
D
E
310 mm
A
700 mm
GCHF
GCHF
H
H
max 282 mm
min 240 mm
G
120 mm
8
8
Type D, mm H, mm A, mm B, mm E, mm
GCHF 6044.. 440 675 277 467 182
GCHF 8044.. 440 855 407 467 182
GCHF 10044.. 440 995 552 467 182
GCHF 12044.. 440 1160 702 467 182
❾
1ⓖ
❿
Type D, mm H, mm A, mm B, mm E, mm L, mm F, mm
GCHFS 8044.. . 440 855 407 467 182
150 252
GCHFS 10044.. 440 995 552 467 182
150 252
GCHFS 12044.. 440 1160 702 467 182
150
252
Type
S, [m
2
] V, [L] P, [MPa] Tmax , [°C]
GCHFS 8044.. .
0.21 0.92 0.6
80
GCHFS 10044..
0.21 0.92 0.6
80
GCHFS 12044..
0.21 0.92 0.6
80
