Rear Display
1. L.Out R.Out
2. Y Cb/Pb Cr/Pr
3. Coax
4. Video
5. S-Video
6. Optical
7. Scart
8. FM/AM
9. Audio Input
10. Audio Output
11. Speaker Output
Left/right mix audio output socket
Y Cb Cr video output socket
Digital audio coaxial output
DVD video output
S-video output socket
Digital audio optical output socket
Scart output
FM/AM antenna
Audio input socket
Audio output socket
Left and right sound output socket
1 2 3,4,5,6 7
8
910
11
