11.5 Blink Code
The bi-colour LED (green/red) on the device flashes to indicate
the various states of the device itself, both while it is connecting
to the display unit and when it is connecting to the vehicle.
The BLINK CODE of the LED is indicated in the table below.
LED
DURATION STATUS
GREEN RED
1 flash every
5 seconds
Off Undefined
Device connected
to the PC
ON Off 2 seconds
Device-vehicle
connection: no
error.
Off Off Undefined
Device ready to
start the trip
ON Off Undefined
Start of trip
detected, diagnosis
system is started
ON Off 10 seconds End of trip detected
3 flashes
every 2
seconds
Off Undefined
Device connected
to the vehicle, data
acquisition in
progress
Off
Quick
flashing
60 seconds
Device connected
to the vehicle
Device NOT
activated or NOT
configured or
generic error
NOTE:
•
Start of trip: engine is turned on.
36
