11.4 Connecting to the OBD socket and Securing the
Device
The device is equipped with a string that allows it to be fastened
securely and prevents it from getting lost.
1.
TMD Nano
2.
String
3.
Terminal
A screwdriver may be necessary to loosen the screws
that fasten the panels that cover the OBD diagnostic
connector.
Make sure the vehicle is off (instrument panel off)
when connecting and disconnecting the device from the
OBD socket.
32
