Table 6-82. Additional
(1)
SPI1 Slave Timings, 4-Pin Chip Select Option
(2)(3)
(continued)
1.3V, 1.2V 1.1V 1.0V
NO. PARAMETER UNIT
MIN MAX MIN MAX MIN MAX
Polarity = 0, Phase = 0,
0.5M+P+4 0.5M+P+5 0.5M+P+6
from SPI1_CLK falling
Polarity = 0, Phase = 1,
P+4 P+5 P+6
from SPI1_CLK falling
Required delay from final SPI1_CLK edge
26 t
d(SPC_SCSH)S
ns
before SPI1_SCS is deasserted.
Polarity = 1, Phase = 0,
0.5M+P+4 0.5M+P+5 0.5M+P+6
from SPI1_CLK rising
Polarity = 1, Phase = 1,
P+4 P+5 P+6
from SPI1_CLK rising
27 t
ena(SCSL_SOMI)S
Delay from master asserting SPI1_SCS to slave driving SPI1_SOMI valid P+15 P+17 P+19 ns
28 t
dis(SCSH_SOMI)S
Delay from master deasserting SPI1_SCS to slave 3-stating SPI1_SOMI P+15 P+17 P+19 ns
