AM1808
www.ti.com
SPRS653E –FEBRUARY 2010–REVISED MARCH 2014
Table 6-118. Video Port Interface (VPIF) Registers (continued)
BYTE ADDRESS ACRONYM REGISTER DESCRIPTION
0x01E1 714C CH3_BC_STRTADR Channel 3 Field 1 chroma buffer start address
0x01E1 7150 CH3_THA_STRTADR Channel 3 Field 0 horizontal ancillary data buffer start address
0x01E1 7154 CH3_BHA_STRTADR Channel 3 Field 1 horizontal ancillary data buffer start address
0x01E1 7158 CH3_TVA_STRTADR Channel 3 Field 0 vertical ancillary data buffer start address
0x01E1 715C CH3_BVA_STRTADR Channel 3 Field 1 vertical ancillary data buffer start address
0x01E1 7160 CH3_SUBPIC_CFG Channel 3 sub-picture configuration
0x01E1 7164 CH3_IMG_ADD_OFST Channel 3 image data address offset
0x01E1 7168 CH3_HA_ADD_OFST Channel 3 horizontal ancillary data address offset
0x01E1 716C CH3_HSIZE_CFG Channel 3 horizontal data size configuration
0x01E1 7170 CH3_VSIZE_CFG0 Channel 3 vertical data size configuration (0)
0x01E1 7174 CH3_VSIZE_CFG1 Channel 3 vertical data size configuration (1)
0x01E1 7178 CH3_VSIZE_CFG2 Channel 3 vertical data size configuration (2)
0x01E1 717C CH3_VSIZE Channel 3 vertical image size
0x01E1 7180 CH3_THA_STRTPOS Channel 3 Top Field horizontal ancillary data insertion start position
0x01E1 7184 CH3_THA_SIZE Channel 3 Top Field horizontal ancillary data size
0x01E1 7188 CH3_BHA_STRTPOS Channel 3 Bottom Field horizontal ancillary data insertion start position
0x01E1 718C CH3_BHA_SIZE Channel 3 Bottom Field horizontal ancillary data size
0x01E1 7190 CH3_TVA_STRTPOS Channel 3 Top Field vertical ancillary data insertion start position
0x01E1 7194 CH3_TVA_SIZE Channel 3 Top Field vertical ancillary data size
0x01E1 7198 CH3_BVA_STRTPOS Channel 3 Bottom Field vertical ancillary data insertion start position
0x01E1 719C CH3_BVA_SIZE Channel 3 Bottom Field vertical ancillary data size
0x01E1 71A0 - 0x01E1 71FF - Reserved
Copyright © 2010–2014, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 225
