3.7.26 Reserved and No Connect
Table 3-28. Reserved and No Connect Terminal Functions
SIGNAL
TYPE
(1)
DESCRIPTION
NAME NO.
Reserved. For proper device operation, this pin must be tied either directly to
RSV2 T19 PWR
CVDD or left unconnected (do not connect to ground).
Reserved. For proper device operation, the pin must be pulled up to supply
RSVDN J17 I
DVDD3318_B.
NC M14, N16 — These pins may be left unconnected or connected to ground (VSS).
NC M3 — These pins should be left unconnected (do not connect to power or ground).
(1) PWR = Supply voltage.
