AM1808
www.ti.com
SPRS653E –FEBRUARY 2010–REVISED MARCH 2014
Table 6-6. AINTC System Interrupt Assignments (continued)
System Interrupt Interrupt Name Source
48 GPIO_B6INT GPIO Bank 6 Interrupt
49 GPIO_B7INT GPIO Bank 7 Interrupt
50 GPIO_B8INT GPIO Bank 8 Interrupt
51 IIC1_INT I2C1
52 LCDC_INT LCD Controller
53 UART_INT1 UART1
54 MCASP_INT McASP0 Combined RX / TX Interrupts
55 PSC1_ALLINT PSC1
56 SPI1_INT SPI1
57 UHPI_ARMINT UHPI ARM Interrupt
58 USB0_INT USB0 Interrupt
59 USB1_HCINT USB1 OHCI Host Controller Interrupt
60 USB1_RWAKEUP USB1 Remote Wakeup Interrupt
61 UART2_INT UART2
62 - Reserved
63 EHRPWM0 HiResTimer / PWM0 Interrupt
64 EHRPWM0TZ HiResTimer / PWM0 Trip Zone Interrupt
65 EHRPWM1 HiResTimer / PWM1 Interrupt
66 EHRPWM1TZ HiResTimer / PWM1 Trip Zone Interrupt
67 SATA_INT SATA Controller
68 T64P2_ALL Timer64P2 - Combined TINT12 and TINT34
69 ECAP0 ECAP0
70 ECAP1 ECAP1
71 ECAP2 ECAP2
72 MMCSD1_INT0 MMCSD1 MMC/SD Interrupt
73 MMCSD1_INT1 MMCSD1 SDIO Interrupt
74 T64P2_CMPINT0 Timer64P2 - Compare 0
75 T64P2_CMPINT1 Timer64P2 - Compare 1
76 T64P2_CMPINT2 Timer64P2 - Compare 2
77 T64P2_CMPINT3 Timer64P2 - Compare 3
78 T64P2_CMPINT4 Timer64P2 - Compare 4
79 T64P2_CMPINT5 Timer64P2 - Compare 5
80 T64P2_CMPINT6 Timer64P2 - Compare 6
81 T64P2_CMPINT7 Timer64P2 - Compare 7
82 T64P3_CMPINT0 Timer64P3 - Compare 0
83 T64P3_CMPINT1 Timer64P3 - Compare 1
84 T64P3_CMPINT2 Timer64P3 - Compare 2
85 T64P3_CMPINT3 Timer64P3 - Compare 3
86 T64P3_CMPINT4 Timer64P3 - Compare 4
87 T64P3_CMPINT5 Timer64P3 - Compare 5
88 T64P3_CMPINT6 Timer64P3 - Compare 6
89 T64P3_CMPINT7 Timer64P3 - Compare 7
90 ARMCLKSTOPREQ PSC0
