Texas Instruments TMS320

TMS320 SECONDGENERATION
DEVICES
SPRS010B — MAY 1987 — REVISED NOVEMBER 1990
POST OFFICE BOX 1443  HOUSTON, TEXAS 77001
45
reset timing
CLKOUT1
RS
A15-A0
D15-D0
PS
STRB
Control
Signals
†
IACK
Serial Port
Control
‡
Fetch
Location 0
Begin
Program
Execution
Valid
Valid
t
d(RS)
t
su(IN)
t
h(IN)
t
su(IN)
t
w(RS)
†
Control signals are DS,IS,R/W, and XF.
‡
Serial port controls are DX and FSX.
ADVANCE INFORMATION
