Texas Instruments TMS320

TMS320C25
SPRS010B — MAY 1987 — REVISED NOVEMBER 1990
POST OFFICE BOX 1443  HOUSTON, TEXAS 77001
49
BIO timing
CLKOUT1
STRB
A15-A0
BIO
FETCH
BIOZ
t
su(IN)
t
h(IN)
FETCH Next Instruction
PC=N PC=N+1 PC=N+2
or Branch Address
Valid
FETCH Branch Address
external flag timing
CLKOUT1
STRB
A15-A0
XF
t
d(XF)
PC=N PC=N+1 PC=N+2 PC=N+3
Valid
FETCH
SXF/RXF
Valid Valid
Valid
ADVANCE INFORMATION
