Texas Instruments TMS320

TMS320C25
SPRS010B — MAY 1987 — REVISED NOVEMBER 1990
POST OFFICE BOX 1443  HOUSTON, TEXAS 77001
53
HOLD timing (part B)
CLKOUT1
CLKOUT2
STRB
HOLD
PS
,DS,
or
IS
R/
W
D15-D0
HOLDA
A15-A0
FETCH
EXECUTE
t
d(C2H-H)
†
In
N+2 N+2
Valid
-- -- -- N + 2
-- -- -- N + 1
t
en(A-C1L)
t
d(HH-AH)
†
HOLD is an asynchronous input and can occur at any time during a clock cycle. If the specified timing is met, the exact sequence shown will occur;
otherwise, a delay of one CLKOUT2 cycle will occur.
ADVANCE INFORMATION
