Digital PFC Description
12.3.6 UCD3138 Resource Allocation for PFC Control
Table 5. J3 and J4 Pin Assignment
UCD3138 CONTROL
HEADER PIN NUMBER DESCRIPTION
CARD PIN NAME
J3-1 DPWM_0A RC filter for debug monitoring
J3-2 DPWM_0B Not used
J3-3 DPWM_1A Not used(available as an option for PFC PWM1)
J3-4 DPWM_1B PFC PWM1
J3-5 DPWM_2A Not used(available as an option for PFC PWM2)
J3-6 DPWM_2B PFC PWM2
J3-7 DPWM_3A PFC ZVS control
J3-8 DPWM_3B AC drop indicator signal
J3-9 DGND Digital ground GND1
J3-10 DGND Digital ground GND1
J3-11 FAULT-0 Inrush relay control
J3-12 Not used Not used
J3-13 FAULT-1 LED 1
J3-14 Not used Not used
J3-15 SYNC Sync input signal for PFC stage
J3-16 Not used Not used
J3-17 FAULT-2 Not used
J3-18 Not used Not used
J3-19 Not used Not used
J3-20 Not used Not used
J3-21 Not used Not used
J3-22 FAULT-3 Not used
J3-23 SCI_TX1 SCI_TX1
J3-24 SCI_RX1 SCI_RX1
J3-25 PWM0 LED 2
J3-26 PWM1 LED 3
J3-27 Not used Not used
J3-28 Not used Not used
J3-29 TCAP Not used
J3-30 Not used Not used
J3-31 SCI TX0 SCI TX0
J3-32 SCI TX0 SCI RX0
J3-33 INT-EXT Not used
J3-34 EXT-TRIG Not used
J3-35 DGND Not used
J3-36 RESET* Not used
J3-37 DGND Digital ground GND1
J3-38 DGND Digital ground GND1
J3-39 +12V_EXT External +12V DC supply
J3-40 3.3VD Not used
J4-01 AGND Analog ground GND2
J4-02 Not used Not used
J4-03 AGND Analog ground GND2
J4-04 AD_00 PMBus address
J4-05 AGND Analog ground GND2
35
SLUU885B–March 2012–Revised July 2012 Digitally Controlled Single-Phase PFC Pre-Regulator
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
To Next Page
