INS881EN-2 18/55
1.3 Wiring, TEOL selection and powering up
The device allows you to wire to control equipment in several different ways. To
aid wiring and inspections of cable termination the terminal block can be tilted
forwards or removed entirely.
TEOL wiring is considered the most secure. The detector is designed to be
connected to a single zone on control panels which feature Triple End-Of-Line
compatibility. Alarm, Tamper, Fault and Masking are signalled on one pair of wires.
To aid installation the resistor values can be selected via dip switches. All the
connections are normally closed. Masking is signalled by the alarm and fault
relays opening simultaneously.
The example shown assumes you are connecting to a Premier Elite control panel.
For other wiring types, please refer to the manufacturer’s instructions for your
equipment.
The device is defaulted no selection.
You MUST change the default position of the TEOL switches
to make the device function.. .
Use a terminal driver to move the switches to the desired position.
All adjustments and mode selections should be made prior to powering up the
device. Anti-mask calibration takes 180s during which time there should be no
activity in the protected area.
Terminal block identification
+ to Aux 12V1.
- to Aux 0V2.
A - TEOL3.
B - TEOL4.
C – Test5.
D – N/A6.
RLED can be used to control the LED for walk testing.7.
