2 INS181-2
1. INSTALLATION
The Premier RKP8/16 Plus remote keypads are suitable for use with the
following Texecom control panels: Premier 412 and Premier 816 with
Version 2.1 or higher panel software. Up to 6 keypads may be connected to
the system.
1.1 Mounting
Open the keypad by carefully inserting a small flat-blade screwdriver into
each slot at the base of the unit. Gently push the screwdriver to ease the
retaining clips upward, DO NOT LEVER OR TWIST. Excessive force is NOT
required. The front flap and front cover can now be removed.
1.2 Selecting an Address
Each keypad MUST be given a different address using the DIP switch on the
left hand side of the PCB as follows:
Address DIP 1 DIP 2 DIP 3 DIP 4
1 Off or On Off Off Off
2 Off On Off Off
3 Off Off On Off
4 Off Off Off On
5 On Off Off On
6 Off On Off On
NEVER set two RKPs to the same address.
Keypads are factory set to Address 1 (all switches off).
