Textron BROUWER TR130 User Manual

350019 6 - 2 rev 12/00
PARTS section 6
Parts List for Figure 1
Ref Part no. De scrip tion Quan tity
1 M5268 ENGINE, HONDA 5.5 HP 1
2 115013 CHAIN, ROLLER #50 X 47-1/4" LG 1
3 81-055 HALF LINK, #50 1
4 81-053 CONNECTOR LINK, #50 1
5 301686 GUARD, CHAIN 1
6 99-K02 FLANGE BOLT, 5/16 X 1 4
7 94-05 FLAT WASHER, 5/16 USS 12
8 95-04 FLAT WASHER, 1/4 SAE 8
10 301429 MOUNT, ENGINE 1
11 F5728 BOLT, 1/2 X 4 GR 5 FULL THREAD 4
12 301723 WASHER, FLAT CUPPED 8
13 M5221 MOUNT, RUBBER 7/16 ID 1-3/8 OD 8
14 F5012 LOCKNUT, 1/2 NYLON JAM 4
15 99-E10 JAM NUT, 1/2 4
16 350003 HANDLEBAR WELDMENT 1
17 350022 DUCT, AIR 1
18 90-0606 BOLT, 3/8 X 3/4 (SERIAL NO. 1001-1398) 6
99-K26 BOLT, FLANGE 1/4 X 3/4 (SERIAL NO. 1399- ) 5
19 96-06 LOCK WASHER, 3/8 (SERIAL NO. 1001-1398) 6
20 90-0624 BOLT, 3/8 X 3 4
21 99-E40 LOCKNUT, NYLON 3/8 4
22 90-0508 BOLT, 5/16 X 1 2
23 95-05 FLAT WASHER, 5/16 SAE 2
24 99-E12 FLANGE NUT, 5/16 2
25 90-0820 BOLT, 1/2 X 2-1/2 2
27 99-E41 LOCKNUT, NYLON 1/2 2
28 90-0822 BOLT, 1/2 X 2-3/4 2
29 96-08 LOCK WASHER, 1/2 2
30 301505 FRAME WELDMENT, FORK 1
31 301522 ROLLER, 8" 1
32 B0002 BEARING, FLANGE 5/8 SET SCREW 2
33 90-0416 BOLT, 1/4 X 2 4
34 99-E39 LOCKNUT, NYLON 1/4 4
35 114025 CHAIN, ROLLER: #40 X 42" LG 1
37 81-056 CONNECTOR LINK, #40 1
38 99-E18 WING NUT, 3/8 1
39 301690 CRANK, FREE WHEEL 1
40 90-0512 BOLT, 5/16 X 1-1/2 4
41 94-05 FLAT WASHER, 5/16 USS 8
42 99-E38 LOCKNUT, NYLON 5/16 4
43 90-0610 BOLT, 3/8 X 1-1/4 1
44 92-06 NUT, 3/8 1
45 95-06 FLAT WASHER, 3/8 SAE 4
