rev 8/96 4 - 2 350019
OPERATION section 4
EN GINE SPEED CON TROL
This control is located on the engine. Set engine
speed between 2/3 and full throttle as desired. For
operation, see the engine manual.
Running engine at low throttle
settings could cause
hydrostatic transmission damage due to
inadequate cooling air flow.
FREE WHEEL CON TROL
The freewheel control allows the turf roller to be
moved by external means when the engine has
been shut off. Release the crank lock and turn the
freewheel control crank clockwise to engage the
freewheel and turn counter clockwise to disengage
the freewheel. Re--lock the control crank with the
crank lock. (See Drawing 2)
Do not activate the freewheel
control when the turf roller is
stopped on an incline or when the engine is
running.
Drawing 2 - Freewheel Control
