THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page D-8
10015775 Service Parts Manual
BRAKES
1 612189 Brake Assembly (Driver Side) (Includes Items 3 - 9) ....................................... 1
2 612211 Brake Assembly (Passenger Side) (Includes Items 3 - 8, 10).......................... 1
3 612411 Brake Shoe, Leading ................................................................................ 1
4 612412 Brake Shoe, Trailing .................................................................................. 1
5 612413 Dust Cover................................................................................................. 1
6 612415 Brake Spring, Top ...................................................................................... 1
7 612414 Brake Spring, Bottom ................................................................................ 1
8 612416 Shoe Clamp............................................................................................... 2
9 612417 Gear Adjuster (Driver Side) ....................................................................... 1
10 612418 Gear Adjuster (Passenger Side)................................................................ 1
11
12
13 17083G2 Hex Head Bolt, 5/16" - 24 x 1" Lg, Grade 8 ..................................................... 4
14 15126G1 Lock Nut, 5/16" - 24 ......................................................................................... 4
15
16 21807G2 Brake Drum Assembly (Includes Items 17, 18) ................................................ 1
17 20947G1 Brake Drum ............................................................................................... 1
18 19862G2 Lug Bolt, 1/2" - 20 X 1.718" Lg .................................................................. 4
19
20
21 21809G1 Flat Washer (Inner Wheel Rim), .984" x 1.31" x .031" ..................................... 1
22 606945 Brake Drum Washer......................................................................................... 1
23 612928 Slotted Hex Nut, 3/4" - 16 ................................................................................ 1
24 10387G1 Cotter Pin, 5/32" x 1 3/4" Lg............................................................................. 1
25 652248 Brake Cable Bracket (Passenger Side) ........................................................... 1
26 652249 Brake Cable Bracket (Driver Side) ................................................................... 1
To Next Page
