PE945/PE961
7
Operation
The test set must have a good 9V battery installed in order to operate.
See “Changing the Battery or Cordset” in this manual.
1. Connect the red wire to the ring (negative) side of the circuit.
2. Connect the black wire to the tip (positive) side of the circuit.
3. Use the Talk, Monitor and Mute features as described in this section.
Automatic Ground Start
Some lines, especially PABX, require a momentary ground to draw a dial tone.
Connect the test set’s red and black wires to the telephone circuit as usual, and connect the
green wire to ground. Press the TALK button momentarily to check for dial tone.
The ground start is automatic, and the green wire can remain connected without affecting the
call.
TAL
Press once to go off-hook (connect). Press MONITOR to go on-hook (disconnect).
▼
Off-Hook Mode
LED: Flashing red (first press)
Tone: Middle Pitch–Middle Pitch
LED: Flashing red (additional presses)
Tone: High Pitch
▼
On-Hook Mode
LED: Flashing green (first press)
Tone: Middle Pitch
LED: None (second press)
Tone: Low Pitch
Automatic Line Checks
The PE945/PE961 is designed to allow testing of POTS service on a live ADSL line without fear of
bringing down the data service. At any attempt to go Off-Hook, the test set automatically
performs the following line checks:
1. Digital Signal Presence (PE961 only): A two-tone alarm
(middle pitch – low pitch)
sounds and the test set locks out. To override this alarm, e.g. on an ADSL line, press and
hold the TALK key until the alarm stops (~ 6 seconds). Once overridden, the alarm will
remain cancelled until the unit is either turned off or disconnected from the line.
2. High DC Level (76V-116V): A single-tone alarm
(low pitch)
sounds, the hook status LED
flashes red and green and the test set locks out. To override this alarm, press and hold the
TALK key until the alarm stops.
3. HIGH DC Level (>116V): A single-tone alarm sounds and the test set locks out. The alarm
may not be overridden.
