TGB CH1 - Maintenance Information; Precautions in Operation

TGB 2. MAINTENANCE INFORMATION
2-1
PRECAUTIONS IN OPERATION .......2-1
PERIODICAL MAINTENANCE SCHEDULE........2-2
LUBRICATION SYSTEM....................2-3
VALVE CLEARANCE ADJUSTMENT 2-4
CARBURETOR IDLING SPEED ADJUSTMENT 2-5
IGNITION SYSTEM/SPARK PLUG ..2-6
CYLINDER COMPRESSION PRESSURE
.2-7
DRIVING SYSTEM............................. 2-7
PRECAUTIONS IN OPERATION
Specification
capacity 850 c.c.
Engine Oil
change 750 c.c.
capacity 120 c.c.
Transmission Gear oil
change 110 c.c.
Clearance of throttle valve 2~6 mm
Spark plug TORCH A7RC Gap: 0.6~0.7 mm
“F” Mark in idling speed Before TDC 13º / 2200 rpm
Full timing advanced Before TDC 26º / 8000 rpm
Idling speed 2200±100 rpm
Cylinder compression pressure 12±2 kg/cm²
Valve clearance: IN/EX 0.06±0.02 mm
