SPECIFICATIONS
MAKER TGB MODEL CH1/CR1
Overall Length 1780mm
Primary
Reduction
BELT
Overall Width 695mm
Secondary
Reduction
GEAR
Overall Height 1075/1170mm Clutch One-way
DIMENSION
Wheel Base 1285mm
Deceleration
equipment
Transmission C.V.T.
Exhaust Pipe Position
and Direction
Right side, and
Backward
Lubrication System Separated-lubrication
WEIGHT
Curb Weight
92/102kg
Solid
Particulate
15 % ↓
Type 4-STROKE ENGINE
CO
2.5±0.5 % ↓
Installation and
arrangement
Vertical, below center,
incline 80°
Exhaust
Concentration
HC Below 800 PPM
Fuel Used Unleaded (92/95) Head 12V 35/35W
Cycle/Cooling
4-stroke/forced air
cooled
Rear 5W
Bore
φ 39.0 mm
Brake 21W
Stroke 41.5 mm
LAMPS
Turn
10W×4
Cylinder
Number/Arran
gement
Single Cylinder/
horizontal
Inflation
Pressure
(Ffront/Rear)
1.75㎏f/㎝
2
/ 2.10㎏f/㎝
2
Displacement 49.5 cc
TIRE
Type F:120/70-12 R:120/70-12
Compression
Ratio
11.8±0.1
Lubricate Oil SAE10W-30(0.85L)
Max. HP 2.35KW/ 7500 rpm Gear Oil SAE 85W-140(0.12L)
Max. Torque 2.96N.m /6500 rpm Battery 12V/5AH
Ignition C.D.I. Brake system F:Disc R:Drum
ENGINE
Starting System Electrical & foot type
