1. GENERAL INFORMATION/TROUBLE DIAGNOSIS TGB
1-2
TORQUE VALUES (ENGINE)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
Cylinder head cover bolts 4 6 0.8~1.2
Cylinder head nuts 4 7 1.0~1.4 Apply oil thread
Cylinder/cylinder head
two-ends bolts
4 7 0.7~1.1 Tighten to crankcase
Cylinder head left bolts 2 6 0.8~1.2
Valve adjustment fixing nuts 2 5 0.7~1.1 Apply oil to thread
Spark plug 1 10 1.0~1.4
Carburetor heat protector
connectin
nuts
2 6 0.7~1.1
Engine oil draining plug 1 12 3.5~4.5
Engine oil strainer cap 1 30 1.3~1.7
Gear oil draining plug 1 8 1.0~1.5
Gear oil filling bolt 1 8 1.0~1.5
Oil pump screws 3 3 0.1~0.3
Engine left side cover bolts 9 6 0.8~1.2
Rubber washer
attached
Camshaft chain tensioner
bolt
1 8 0.45~0.6 Hex socket bolt
Camshaft chain adjuster
bolts
2 6 0.8~1.2
Clutch driving plate nut 1 28 5.0~6.0
Clutch outer bracket nut 1 12 3.5~4.5
Driving disk nut 1 10 3.5~4.5
Flywheel nut 1 10 3.5~4.5
Crankcase bolts 9 6 0.8~1.2
Gear box cap bolts 7 8 2.6~3.0
Exhaust pipe bolts 2 6 0.7~1.1
