TGB CH1 - Standard Torque Values for Reference

TGB 1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-3
The torque values listed in above table are for more important tighten torque values. Please see
standard values for not listed in the table.
Standard Torque Values for Reference
TYPE TIGHTEN TORQUE TYPE TIGHTEN TORQUE
5mm bolt、nut
0.45~0.60kgf-m
3mm screw
0.05~0.08kgf-m
6mm bolt、nut
0.80~1.20kgf-m 4mm screw 0.10~0.15kgf-m
8mm bolt、nut
1.80~2.50kgf-m 5mm screw 0.35~0.50kgf-m
10mm bolt、nut
3.00~4.00kgf-m
6mm screw、SH nut
0.70~1.10kgf-m
12mm bolt、nut
5.00~6.00kgf-m
6mm bolt、nut
1.00~1.40kgf-m
8mm bolt、nut
2.40~3.00kgf-m
10mm bolt、nut
3.50~4.50kgf-m
