TGB 10. A.C. GENERATOR/STARTING CLUTCH
10-1
PRECAUTIONS IN OPERATION .......10-1
A.C.GENERATOR REMOVAL ...........10-2
RIGHT CRANKCASE COVER REMOVAL .10-3
RIGHT CRANKCASE COVER INSTALLATION....10-4
MOUNTED COIL SET INSTALLATION
........10-4
FLY WHEEL INSTALLATION.............10-4
PRECAUTIONS IN OPERATION
General information
y Refer to chapter 5: Engine removal and installation
y Refer to chapter 1: The troubleshooting and inspection of A.C. generator
Specification Unit: mm
Item Service Limit
ID of starting driven gear 32.060
OD of starting clutch cover 27.940
Torque value:
Flywheel nut 3.5~4.5kgf-m
Exhaust muffler bolt 6 mm 0.7~1.1kgf-m
Oil screen cover 1.3~1.7kgf-m
Special service tools
Flywheel puller
Universal fixture
