TGB CH1 - A.C. Generator Removal

10. A.C. GENERATOR/STARTING CLUTCH TGB
10-2
A.C. GENERATOR REMOVAL
Drain out the engine oil.
Remove the exhaust muffler. (2 bolts, 2 nuts)
Remove the fan shroud.
Remove the fan. (4 bolts)
Hold the flywheel with the universal fixture.
Remove the nut on the flywheel.
Special Service Tools:
Universal Fixture
Flywheel
Cooling fan
Cooling
f
an
shroud
Coil
Pulse generator
Universal fixture
Cooling fan
Exhaust muffler
Cooling fan shroud
