TGB 11. CRANKCASE/CRANKSHAFT
11-3
Remove the crankshaft from the right
crankcase.
Caution
Remove gasket and dowel pins (2).
Scrape gasket residues off the crankcase
contact surface.
Caution
Remove oil seal from the left crankcase.
z Do not damage contact surface of the
crankcase.
z Soap the gasket residues into solvent
and the residues will be removed
easily.
z The left and right bearings of crankshaft
is to press-fit onto the crankshaft.
