SOLAR PANEL AND MOTOR MODULE ASSEMBLY
First, follow the steps starting here to assemble
the solar gearbox. Then use the solar gearbox
to assemble each model, one at a time.
PULL
P8x2
A13
6
3
P2
P1
Correct
Incorrect
1
4
2
Note: You may need to adjust how much the motor
axle sticks out of P2 when you get to step 1 on the
next page, to get P2 and P3 to mesh properly.
Remove
paper from
both sides.
Remove protective
film, if present.
To Next Page
