The Source SOURCE04BLP - Assembly Instructions: Main Grill Body; Mounting the Grill Head onto the Cart

34 pages

To Next Page

To Previous Page

1. With an assistant, lift and position the Grill Head onto the Grill Cart.

2. Align the 3 holes of Right Bowl Side Panel to the thread holes on the Cart Right Side Panel. Tighten securely by

using 3 of the 1/4"x1" Flat Head Screws.

3. Align the 3 holes of Left Bowl Side Panel to the thread holes on the Cart Left Side Panel. Tighten securely by using

3 of the 1/4"x1" Flat Head Screws.

Install The Grill Head

Countersink Flat Head Screw 1/4"x1"

Qty. 6

Ref. # S142G04161
