A user configuration can be created in this submenu.
1. Operate the [ENTER] button and then [NEXT] to activate the "design a Xover" option.
2. Select the desired mode with the [NEXT] / [BACK] buttons or with the jog wheel, e.g.
"type: 2×2 way crossover“.
3. Confirm the selection with [ENTER]. The display shows ‘out 3&4 source B’. Use the [NEXT] /
[BACK] buttons or the jog wheel to select the desired channel assignment.
Since the channels cannot be freely assigned to the controller channels, the
sum formation function "source A+B" should not be assigned here. This can
lead to problems in stereo operation. The controller assigns the channels as fol‐
lows: INPUT A to OUTPUT 1 and 2, INPUT B to OUTPUT 3 and 4.
4. Confirm your selection with [ENTER]. The display shows ‘stereo links: off’. Use the [NEXT] /
[BACK] buttons or the jog wheel to select the desired option.
The "stereo links" option can be selected when the channels OP (OUTPUT) 1 and
3 as well as 2 and 4 are parameterised identically. The OUT1+3 and OUT2+4
values are then copied automatically and do not have to be entered repeatedly.
"design a Xover"
Functions
DS 2/4
19
