1. Press the [EDIT] button assigned to the desired channel.
ð
The settings menu for the desired channel will open. The display shows
‘GAIN’.
2. In the basic state of the menu, you can set the level of the channel within a
range of –60 dB…+12 dB using the jog wheel.
3. Press the respective button to set further parameters for the channel.
Use the jog wheel to set the desired value of the parameter. Press the jog
wheel to confirm.
The table below shows the available parameters and their ranges.
Param-
eter
Button Selection range Meaning
‘PEQ’ 1 ×
[PEQ/GEQ]
‘PEQ’: ‘1’…‘9’
‘F’: ‘20Hz’…‘20kHz’
‘Q’: ‘0.4’…‘128’
‘G’: ‘-12dB’…‘+12dB’
‘Style’: ‘PEAK’, ‘L-SHLF’, ‘H-SHLF’, ‘LP6dB’,
‘LP12dB’, ‘HP6dB’, ‘HP12dB’, ‘A-PAS1’, ‘A-PAS2’
‘ON’, ‘BP’
For 9 frequency bands (numbered with the
parameter ‘PEQ’), the parameters of the para-
metric equalizer can be set individually: Centre
frequency, filter quality, slope, filter type, bypass
‘INLINK’ [LINK] The settings of several output channels can be
linked to each other. The number of output chan-
nels depends on the device design.
‘DELAY’ [DELAY] ‘0ms’ … ‘680ms’
‘0m’…‘234m’
‘0ft’…‘766ft’
Delay time. The units that are displayed depends
on the device's default setting.
‘X-OVER’ [X-OVER] ‘HP’: ‘20Hz’…‘20kHz’
‘LP’: ‘20Hz’…‘20kHz’
‘BUTTER-xx’ (Butterworth), ‘BESSEL-xx’ (Bessel),
‘LINK/R-xx’ (Linkwitz-Riley), ‘BYPASS’ (Filter
switched off)
Parameters for digital high pass and low pass:
Cut-off frequency, slope and filter type
‘MATRIX’ 1 ×
‘MATRIX’
Selection of the assignment of the input channels
to the respective output channel. Each output
channel can be freely assigned to one input
channel or a mix of several input channels. The
selected input channels are marked with ‘X’.
‘MATRIX
Output’
2 ×
‘MATRIX’
‘-60dB’…‘+0dB’ One level adjustment can be set for each of the
input channels assigned to the respective output
channel.
Output settings
Operating on the unit
Digital speaker management system
16
