8 Technical specifications
Inputs Type XLR
Level +18 dBu (max.)
Impedance 1 MΩ (stereo), 500 kΩ (mono)
Outputs Type XLR
Level +20 dBu (max.)
Impedance < 500 Ω
Frequency response 20 Hz … 20 kHz
Distortion (THD) < 0.005 % (1 kHz, 0 dBu)
Signal-to-noise ratio > 115 dBu
Crosstalk < 100 dB
Digital signal processor Resolution 24 bit
Sampling rate 96 kHz
Voltage supply
100 – 240 V 50/60 Hz
Power consumption 20 W
Fuse 5 mm × 20 mm, 2 A, 250 V, slow-blow
Dimensions (W × H × D) 480 × 45 × 24.5 mm
Weight 2.62 kg
Block diagram
Technical specifications
DSP 204, DSP 206, DSP 306, DSP 408
29
