The t.racks DSP 408 User Manual

8 Technical specifications
Inputs Type XLR
Level +18 dBu (max.)
Impedance 1 MΩ (stereo), 500 kΩ (mono)
Outputs Type XLR
Level +20 dBu (max.)
Impedance < 500 Ω
Frequency response 20 Hz … 20 kHz
Distortion (THD) < 0.005 % (1 kHz, 0 dBu)
Signal-to-noise ratio > 115 dBu
Crosstalk < 100 dB
Digital signal processor Resolution 24 bit
Sampling rate 96 kHz
Voltage supply
100 – 240 V 50/60 Hz
Power consumption 20 W
Fuse 5 mm × 20 mm, 2 A, 250 V, slow-blow
Dimensions (W × H × D) 480 × 45 × 24.5 mm
Weight 2.62 kg
Block diagram
Technical specifications
DSP 204, DSP 206, DSP 306, DSP 408
29

The t.racks DSP 408 Specifications

General

Brand	The t.racks
Model	DSP 408
Category	Speaker System
Language	English
