6 Operating on the unit
Connect the device to the power grid and turn it on with the main switch to start
operation. After a few seconds, the display indicates that a reset is in progress. The
device is then ready for use. The display shows the model name and the user preset
that's currently active.
The device can only be operated directly with the buttons if it is not being controlled
via USB, LAN or the serial interface.
The buttons that can currently be used light up continuously, and the most previ-
ously used ones flash on and off. Buttons that cannot be used at the moment
remains dark.
1. Keep pressing [UTIL] until the parameter you want appears in the display.
The table below shows the available parameters and their ranges.
2. Use the jog wheel to set the desired value of the parameter. Press the jog
wheel to confirm.
3. Press [EXIT].
Parameter Selection range Meaning
‘ID Number Select’ ‘1’…‘254’ Unique identification of the device when connected serially (in
a cascade configuration). If several devices are connected seri-
ally, each of them must have a unique ID number.
‘Manual IP Set’ If the device is connected to a local network, its IP address can
be set individually. The initial IP address is
192.168.1.101
.
‘Unit Lock PassWord’ ‘0000’…‘ZZZZ’ Four-character device password. Any combination of letters or
numbers can be set. The initial password is
1234
.
‘Input Source Select’ ‘ANALOG INPUT’, ‘PINK NOISE’,
‘WHITE NOISE’, ‘SINE xx’
Selection of the signal source: Either the analogue inputs or
the internal test tone generator. The test tone generator can
produce either: pink noise, white noise or a sine wave of
20 Hz…20 kHz.
‘Copy CH select’ Copies the settings from one channel to another.
‘Delay Units Select’ ‘ms’, ‘m’, ‘ft’ Selects the unit for displaying the delay: Milliseconds, metres
or feet.
Starting the device
Default settings
Operating on the unit
Digital speaker management system
12
