52 NOVA OPERATION
EXTERNAL CONNECTIONS
POWER Internal power supply switchable to 120 or 220/240 VAC 50/60 Hz, 5 watts, via IEC 630 male socket,
DIMMER OUTPUT EIA-485 250 K Baud to DMX-512 1990 standard via 5 pin Cannon XLR female socket.
REMOTE STEP Two channel short to earth via 6.25 mm Stereo jack socket.
AUDIO INPUT 100 millivolts input via 6.25 mm Stereo jack socket.
DIMENSIONS
NOVA MODELS Length Depth Height Weight
24 channel Nova 500mm 295mm 88mm 7.5Kg
36 channel Nova 738mm 295mm 88mm 9.5Kg
