4
6. Specifications:
Operating temperature: 0°C to 40°C
Operating voltage: 230V 50Hz
Switch rating: 16A resistive,
8A inductive,
1 HP, 750W incandescent,
750W halogen,
750W fluorescent,
100W compact fluorescent.
Switch type: 22A micro switch
Voltage free contact: Yes, if wire link is
removed
Contact type: Normally open and
normally closed
Power ON light: Yes
Output Light: No
Time period: 24 hours
Note:
Product not suitable for discharge lighting.
5. Permanent Override:
The main slider on the timer can be set to permanent
ON by sliding it to the left, aligning the arrow head
to the 1 symbol.
In the middle position, with the arrow head pointing
at the timer symbol, the timer is in automatic mode.
If the slider is moved to the right, and the arrow head
points at the 0 symbol, the timer is permanently OFF.
