If you nd any broken or damaged parts during the disassembly
or cleaning process or for additional help, please contact
The Pond Guy Technical Support at (586) 589-7422.
Step 12
Reinstall Motor Housing
Slide the stainless steel body down and onto the lower
trim ring (12a). Holding the top housing with one hand
and the internal pump cord in the other, slide the top
housing back down the cord, onto the stainless steel
body (12b).
Step 13
Assemble Base
Reinstall the four top housing screws (13a).
Tighten the two pump cord strain relief screws (13b).
Set the ball oat back into the bottom side of the pump
motor mounting base (13c).
NOTE: Do not over-tighten any screws during
reassembly. Screws should be snug but not so tight
that they could cause the plastic to crack.
12a
12b
13a
13b
13c
15425 Chets Way | Armada, MI 48005
13
EXTENDED MAINTENANCE RAPIDFLO PUMP:
