Thermaltake TH240 ARGB Sync User Manual

S
ARGB Controller Installation Guide
1. Light Mode:
Switch over between 7 LED modes.
3. Light Speed:
Switch over between 4 light modes.
When light mode is in RGB Spectr um:
Click to memorize and lock the color you want, click again to unlock the 256
colors auto rotation.
Red → Yellow → Green → Teal → Blue → White → Purple
When light mode is in Ripple :
Switch over 7 LED colors .
When light mode is in Wave and Flow :
LED color can not be adjusted.
Red → Yellow → Green → Teal → Blue → White → Purple → Rainbow
2. Color Mode:
When light mode is in Full Lighted, Pulse and Blink :
Switch over 8 LED colors .
Rainbow → Full light → RGB Spectrum → Off → Flow → Ripple → Pulse → Blink
Slow → Normal → Fast → Extreme
P
P
Q
Q
A
MB SYNC Installation Guide
Please power off the PC and check the Positive and Negative
ends on the connector before connecting the cable to
mainboard. Connecting the wrong end can damage the fans.
CAUTIONCAUTION
AOURS RGB Fusion with Digital LEDs
GIGABYTE
E
F
JRGB-strip Header(S)
MSIMSI
E
+5V D G
JRAINBOW
G
Q
Q
A
F
E
Installation Guide
1
1
K
2
2
3 4
Q
Q
A
SATA
Q
J
A
FAN
CPU_FAN
Q
© 2019 Thermaltake Technology Co., Ltd. All Rights Reserved.
www.thermaltake.com
Aura Addressable Strip Header(s)
ASUS/ASRock/BIOSTAR
Intel
or
AMD
PUMP
SYS_F AN
A
PUMP
SYS_F AN
A

Thermaltake TH240 ARGB Sync Specifications

General

Radiator Material	Aluminum
Tube Length	400 mm
Pump Rated Voltage	12 V
Pump Rated Current	0.38 A
Pump Power Consumption	4.56 W
Fan Dimensions	120 x 120 x 25 mm
Fan Speed	1500 RPM
Fan Air Flow	59.28 CFM
Fan Static Pressure	1.31 mm-H2O
Fan Rated Voltage	12 V
Bearing Type	Hydraulic Bearing
Life Expectation	40, 000 hours
LED Type	ARGB
Warranty	3 years
Fan Noise Level	28.2 dB-A
Compatibility	Intel LGA 2066/1200/1156/1155/1151/1150, AMD AM4/AM3+/AM3/AM2+/AM2
Pump Speed	3300 ± 10% RPM
