Contents
1 2
Chapter 1. Product Introduction
Chapter 2. Installation Guide
2.1
2.2
2.3
2.4
2.5
2.6
2.7
1.1
1.2
1.3
02
02
03
05
06
07
08
10
11
11
Specification
Accessory
Warning and Notice
Side Panel Disassembly
PSU Installation
Motherboard Installation
3.5" & 2.5" HDD Installation
Chapter 3. Leads Installation
Case LED Connection
USB 2.0 Connection
USB 3.0 Connection
Audio Connection
3.1
3.2
3.3
3.4
12
12
12
12
Chapter 4. Other
4.1
18
Thermaltake Power Supply Series (Optional)
*Picture for reference only
*Information in the user manual is subject to change without notice
PCI Slot Usage
Radiator Installation
Air Cooling Installation
Radiator Support
Front: 1 x 240mm , 1 x 280mm
Rear: 1 x 120mm
Micro Case
Case Type
SPCC
Material
Clearance
CPU cooler height limitation: 155mm
VGA length limitation: 350mm(Without Front Fan)
PSU length limitation: 220mm
Drive Bays
-Accessible
-Hidden
-
2 x 2.5" ; 2 x 3.5”
Fan Support
Front: 3 x 120mm , 2 x 140mm
Top: 1 x 120mm , 1 x 140mm
Rear: 1 x 120mm
Dimension (H*W*D) 390 x 205 x 380mm (15.4 x 8.1 x 15 inch)
Side Panel
Versa H17
Model
Versa H17(Window)
No Window Transparent Window
Rear (exhaust) :
120 x 120 x 25 mm fan (1000rpm, 16dBA)
Cooling System
Stand-off #6-32 x 6mm
2
Motherboard
Screw M3 x 5mm
12
Motherboard
Screw #6-32 x 6mm
4
Power
Screw M3 x 5mm
10
2.5" HDD
Screw #6-32 x 6mm
10
3.5" HDD
Screw T5 x 12mm
2
Case Fan
HDD/SSD Rubber
20
Motherboard
CableTie
5
Cable Management
Buzzer
1
Motherboard Alarm
Figure
Parts Name
Q'ty
Used for
