Chapter 1. Product Introduction
Chapter 2. Installation Guide
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
1.1
1.2
1.3
02
02
03
05
06
07
08
10
11
13
14
Contents
1 2
Specification
Accessory
Warning and Notice
Side Panel Disassembly
PSU Installation
Motherboard Installation
5.25" Device Installation
External 3.5” Device Installation
HDD Installation
2.5" HDD Installation
PCI Slot Usage
Chapter 3. Leads Installation
Case LED Connection
USB 2.0 Connection
USB 3.0 Connection
Audio Connection
3.1
3.2
3.3
3.4
15-20
15-20
15-20
15-20
Chapter 4. Other
4.0
21
Thermaltake Power Supply Series (Optional)
Stand-off #6-32 x 6mm
Screw #6-32 x 6mm
Screw #6-32 x 5mm
Screw M3 x 5mm
Screw #6-32 x 29mm
21
16
Motherboard, HDD
For ODD, FDD, 2.5” HDD
For Front Fan
*Picture for reference only
*Information in the user manual is subject to change without notice
VO700A1N3N VO700A1W3NP/N
Versa II
Versa G2
Mid Tower
429 x 196 x 480 mm
(16.9 x 7.7 x 18.9 inch)
PSU
LCS Upgradable
Exterior : Black Exterior & Interior : Black
Net Weight
SGCC
Front (intake) : Optional
120 x 120 x 25 mm fan x 1
Rear (exhaust) :
120 x 120 x 25 mm Blue LED fan (1000rpm,16dBA)
(For VO700A1W3N only)
Top (exhaust) : Optional
120 x 120 x 25 mm fan x 2
Side (intake) : Optional
120 x 120 x 25 mm fan
Bottom (intake) : Optional
120 x 120 x 25 mm fan
3 x 5.25’’, 1 x 3.5’’
5x 3.5’’, 1 x 2.5”
7
9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
USB 3.0 x 1, USB 2.0 x 1, HD Audio x 1
Standard PS2 PSU
Supports 1/2”, 3/8”,1/4” water tube
4.5Kg / 9.9lb
Side Panel
N/A Transparent Window
