M 540211001224082018
THERMEX VERTICAL ATOMATIC
39
ENGLISH
»
INSTALLATION
Attach both parts of the duct to the lower-
most bracket using two screws.
20
Attach the lowermost part of the duct to the
flange of the hood using two screws.
21
19
Connect the hood to the mains socket using
the attached Schuko plug.
NOTE: The hood must be earthed.
