THERMEX VERTICAL AUTOMATIC
M 540211001224082018
38
ENGLISH
»
INSTALLATION
Drill the holes and install rawlplugs suitable for
the material into which they are installed.
11
Mount the brackets on the duct.
12
10
Mount the hood on the bracket.
Fix the hood to the wall by mounting the
screws in the locking holes.
13
Replace the filters inside the hood.
14
The lid of the hood is closed by activating and
holding down the on/o icon until it closes.
15
Place the extraction hose on the hood.
NOTE: This does not apply if the hood is used
for recirculation.
16
Place the duct on the hood.
17
Pull up the top part of the duct and secure it to
the uppermost bracket to the duct using two
screws.
18
x6
x2
x4
x2
