THERMO 2000 MINI BTH - Replacement Parts

Electric boilers MINI BTH Installation & Operating Manual (Revision: May 2015), 14
5.2 REPLACEMENT PARTS
Figure 9 : Replacement parts (Front)
Figure 10 : Replacement parts (top)
** When replacing a heating element, insure that its orientation is identical as the original.
Heating elements**
3kW : ZEL300-240V3KW
4.5kW : ZEL300-240V45KW
6kW : ZEL300-240V6KW
Fuse
ZEL250-TDMIDJ15
High limit
(automatic reset)
ZEL200-L6C732
Temperature control
ZEL200-G111781
Pressure Relief valve
ZMC200-SV30PSI1
Indicating lamp
ZEL150-240VRED
Contactor bobine 24Vac
Modèle 3; 4.5; 7.5; 9kW :
ZEL100-2PC5024
Modèle 12kW : ZEL100-4P50A24
Pump Relay
ZEL100-24ACSPST
Transformer 208/240Vx24Vac
ZEL400-20842440
Temperature & Pressure
indicator
ZMC300-75P160CN
