Thermo Dynamics CWL - Preliminary Settings

INSTALLER/SERVICEMAN
DIRECT VENT
Model Number CWL-85DV CWL-100DV CWL-110DV
Burner Type Carlin* Carlin* Carlin*
Burner Model EZ-1 EZ-1 EZ-1
Nozzle Type .75 60B .85 60B 1.00 60B
Pump Pressure PSI 140 140 140
Head/Pin Position 75 75 85-100
Air Band 85 125 140
Air Shutter N/A N/A N/A
Draft Over Fire +0.03" -0.04" +0.06"
Draft In Stack +0.03" +0.03" +0.03"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
*Requires Carlin Air Intake Adapter Use 60° HAGO Nozzle
NOTICE
Above settings are approximate. Final adjustments to be made
with proper test equipment. Be sure all oil lines are air free and
the use of flare fittings is recommended. See installation/ser-
vice manual for detailed information.
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
INSTALLER/SERVICEMAN
M
odel Number CWL-85 CWL-100 CWL-110
Burner Type Carlin Carlin Carlin
Burner Model EZ-1PRO EZ-1PRO EZ-1PRO
Nozzle Type .70 60°W .85 60°W .90 60°W
Pump Pressure PSI 150 150 150
Head/Pin Position .75 .85-1.00 .85-1.00
Air Band .65 .85 .90
Air Shutter N/A N/A N/A
Draft Over Fire 0 to + 0.10" 0 to + 0.10" 0 to + 0.10"
Draft In Stack -0.02" -0.02" -0.02"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
NOTICE
Above settings are approximate. Final adjustments to be made
with proper test equipment. Be sure all oil lines are air free and
the use of flare fittings is recommended. See installation/ser-
vice manual for detailed information.
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
Preliminary Settings
25
INSTALLER/SERVICEMAN
Model Number CWL-85 CWL-100 CWL-110
Burner Type Riello Riello Riello
Burner Model F-5 F-5 F-5
Nozzle Type .65 60W .75 60W .85 60W
Pump Pressure PSI 180 180 180
Head/Pin Position 0.0 0.0 0.0
Air Band N/A N/A N/A
Air Shutter 2.5 3.0 6.0
Draft Over Fire +0.02" +0.04" +0.06"
Draft In Stack -0.02" -0.02" -0.02"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
NOTICE
Above settings are approximate. Final adjustments to be made
with proper test equipment. Be sure all oil lines are air free and
the use of flare fittings is recommended. See installation/ser-
vice manual for detailed information.
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
_________________________
INSTALLER/SERVICEMAN
DIRECT VENT
Model Number CWL-85DV CWL-100DV CWL-110DV
Burner Type Riello Riello Riello
Burner Model BF5 BF5 BF5
Nozzle Type .65 60W .75 60W .85 60W
Pump Pressure PSI 180 180 180
Head/Pin Position 0.0 0.0 0.0
Air Band N/A N/A N/A
Air Shutter 3.6 4.9 7.0
Draft Over Fire 0 to +.1" 0 to +.1" 0 to +.1"
Draft In Stack -0.02" -0.02" -0.02"
CO
2
Reading 10-11.5% 10-11.5% 10-11.5%
Smoke Reading ZERO ZERO ZERO
NOTICE
Above settings are approximate. Final adjustments to be made
with proper test equipment. Be sure all oil lines are air free and
the use of flare fittings is recommended. See installation/ser-
vice manual for detailed information.
